Single Door Recess
Double Door Recess
Double Door Off-Center Recess
Triple Door Recess
Triple Door Recess *Double Strip
Narrow Chrome
Narrow Matte Black
Narrow Brushed Nickel
Narrow Gold
Narrow Polished Nickel
Narrow White
Narrow Polished Gold
PHAROS COLLECTION (30″ HEIGHT) 5 3/16 & 6 5/8″ DEPTH
Available Narrow Door Finish Options:
AVAILABLE IN 3500 KELVIN OR 6000 KELVIN COLOR TEMPERATURE OPTION
Download our wiring manual here
|
MODEL NUMBER |
OUTER |
ROUGH |
SINGLE |
DOUBLE |
TRIPLE |
5 3/16 DEPTH
(1) |
6 5/8 DEPTH (2) |
5 3/16 DEPTH
(1) |
6 5/8 DEPTH (2) |
|---|---|---|---|---|---|---|---|---|---|
|
|
|
|
|
|
|
POL. |
POL. |
POL. |
POL. |
|
15 X 30 |
14 3/8 X 29 3/8 |
YES |
NO |
NO |
879 |
1011 |
1622 |
1853 | |
|
18 X 30 |
17 3/8 X 29 3/8 |
YES |
NO |
NO |
952 |
1095 |
1778 |
2030 | |
|
21 X 30 |
20 3/8 X 29 3/8 |
YES |
NO |
NO |
1000 |
1150 |
1878 |
2145 | |
|
24 X 30 |
23 3/8 X 29 3/8 |
YES |
NO |
NO |
1036 |
1190 |
2036 |
2319 | |
|
24 X 30 |
23 3/8 X 29 3/8 |
NO |
12 + 12 |
NO |
1108 |
1273 |
N/A |
N/A | |
|
27 X 30 |
26 3/8 X 29 3/8 |
NO |
12 + 15 |
NO |
1180 |
1358 |
N/A |
N/A | |
|
30 X 30 |
29 3/8 X 29 3/8 |
NO |
15 + 15 |
NO |
1253 |
1441 |
N/A |
N/A | |
|
30 X 30 |
29 3/8 X 29 3/8 |
NO |
12 + 18 |
NO |
1253 |
1441 |
N/A |
N/A | |
|
33 X 30 |
32 3/8 X 29 3/8 |
NO |
15 + 18 |
NO |
1326 |
1524 |
N/A |
N/A | |
|
36 X 30 |
35 3/8 X 29 3/8 |
NO |
18 + 18 |
NO |
1399 |
1607 |
N/A |
N/A | |
|
36 X 30 |
35 3/8 X 29 3/8 |
NO |
15 + 21 |
NO |
1399 |
1607 |
N/A |
N/A | |
|
36 X 30 |
35 3/8 X 29 3/8 |
NO |
NO |
12+12+12 |
1561 |
1795 |
N/A |
N/A | |
|
39 X 30 |
38 3/8 X 29 3/8 |
NO |
15 + 24 |
NO |
1657 |
1906 |
N/A |
N/A | |
|
42 X 30 |
41 3/8 X 29 3/8 |
NO |
21 + 21 |
NO |
1705 |
1962 |
N/A |
N/A | |
|
42 X 30 |
41 3/8 X 29 3/8 |
NO |
18 + 24 |
NO |
1705 |
1962 |
N/A |
N/A | |
|
42 X 30 |
41 3/8 X 29 3/8 |
NO |
NO |
12+18+12 |
1912 |
2198 |
N/A |
N/A | |
|
45 X 30 |
44 3/8 X 29 3/8 |
NO |
21 + 24 |
NO |
1984 |
2281 |
N/A |
N/A | |
|
45 X 30 |
44 3/8 X 29 3/8 |
NO |
NO |
15+15+15 12+21+12 |
2056 |
2365 |
N/A |
N/A | |
|
48 X 30 |
47 3/8 X 29 3/8 |
NO |
24 + 24 |
NO |
2129 |
2448 |
N/A |
N/A | |
|
48 X 30 |
47 3/8 X 29 3/8 |
NO |
NO |
15+18+15 12+24+12 |
2201 |
2532 |
N/A |
N/A | |
|
51 X 30 |
50 3/8 X 29 3/8 |
NO |
NO |
15+21+15 |
2275 |
2615 |
N/A |
N/A | |
|
54 X 30 |
53 3/8 X 29 3/8 |
NO |
NO |
18+18+18 15+24+15 |
2347 |
2699 |
N/A |
N/A | |
|
57 X 30 |
56 3/8 X 29 3/8 |
NO |
NO |
18+21+18 |
2433 |
2799 |
N/A |
N/A | |
|
60 X 30 |
59 3/8 X 29 3/8 |
NO |
NO |
18+24+18 |
2579 |
2966 |
N/A |
N/A | |
|
63 X 30 |
62 3/8 X 29 3/8 |
NO |
NO |
21+21+21 |
2651 |
3050 |
N/A |
N/A | |
|
66 X 30 |
65 3/8 X 29 3/8 |
NO |
NO |
21+24+21 |
2724 |
3132 |
N/A |
N/A | |
|
69 X 30 |
68 3/8 X 29 3/8 |
NO |
NO |
24+21+24 |
2965 |
3407 |
N/A |
N/A | |
|
72 X 30 |
71 3/8 X 29 3/8 |
NO |
NO |
24+24+24 |
3042 |
3496 |
N/A |
N/A |
Looking for items in this collection as a wall mirror only? Click here.
Need a mounting kit to surface mount? Click here.
30″ HEIGHT DOUBLE STRIPS* OPTION:ALL PHAROS MULTIPLE DOOR CABINETS STANDARD WITH ONE STRIP OF LIGHT PER LEFT & RIGHT DOOR. WHEN REQUIRING TWO STRIPS OF LIGHT PER DOOR, ADD $378 TO THE COST OF THE CABINET AND SPECIFY DOUBLE STRIPS OPTION WHEN ORDERING.* TO ORDER THIS OPTION ADD A -2 FOLLOWING THE # OF DOORS IN YOUR CABINET’S MODEL NO. EXAMPLE: PHA 4530 3D-2 P 6 A (1). (THIS CABINET WOULD HAVE 2 STRIPS OF LIGHT IN EACH OUTER DOOR).
PHAROS COLLECTION (36″ HEIGHT) 5 3/16 & 6 5/8″ DEPTH
Available Narrow Door Finish Options:
AVAILABLE IN 3500 KELVIN OR 6000 KELVIN COLOR TEMPERATURE OPTION
Download our wiring manual here
|
MODEL NUMBER |
OUTER |
ROUGH |
SINGLE |
DOUBLE |
TRIPLE |
5 3/16 DEPTH
(1) |
6 5/8 DEPTH (2) |
5 3/16 DEPTH
(1) |
6 5/8 DEPTH (2) |
|---|---|---|---|---|---|---|---|---|---|
|
|
|
|
|
|
|
POL. |
POL. |
POL. |
POL. |
|
15 X 36 |
14 3/8 X 35 3/8 |
YES |
NO |
NO |
1029 |
1184 |
1960 |
2203 | |
|
18 X 36 |
17 3/8 X 35 3/8 |
YES |
NO |
NO |
1115 |
1281 |
2111 |
2381 | |
|
21 X 36 |
20 3/8 X 35 3/8 |
YES |
NO |
NO |
1171 |
1347 |
2233 |
2476 | |
|
24 X 36 |
23 3/8 X 35 3/8 |
YES |
NO |
NO |
1212 |
1393 |
2375 |
2645 | |
|
24 X 36 |
23 3/8 X 35 3/8 |
NO |
12 + 12 |
NO |
1297 |
1492 |
N/A |
N/A | |
|
27 X 36 |
26 3/8 X 35 3/8 |
NO |
12 + 15 |
NO |
1381 |
1589 |
N/A |
N/A | |
|
30 X 36 |
29 3/8 X 35 3/8 |
NO |
15 + 15 |
NO |
1466 |
1686 |
N/A |
N/A | |
|
30 X 36 |
29 3/8 X 35 3/8 |
NO |
12 + 18 |
NO |
1466 |
1686 |
N/A |
N/A | |
|
33 X 36 |
32 3/8 X 35 3/8 |
NO |
15 + 18 |
NO |
1551 |
1783 |
N/A |
N/A | |
|
36 X 36 |
35 3/8 X 35 3/8 |
NO |
18 + 18 |
NO |
1636 |
1882 |
N/A |
N/A | |
|
36 X 36 |
35 3/8 X 35 3/8 |
NO |
15 + 21 |
NO |
1636 |
1882 |
N/A |
N/A | |
|
36 X 36 |
35 3/8 X 35 3/8 |
NO |
NO |
12+12+12 |
1825 |
2098 |
N/A |
N/A | |
|
39 X 36 |
38 3/8 X 35 3/8 |
NO |
15 + 24 |
NO |
1939 |
2229 |
N/A |
N/A | |
|
42 X 36 |
41 3/8 X 35 3/8 |
NO |
21 + 21 |
NO |
1996 |
2296 |
N/A |
N/A | |
|
42 X 36 |
41 3/8 X 35 3/8 |
NO |
18 + 24 |
NO |
1996 |
2296 |
N/A |
N/A | |
|
42 X 36 |
41 3/8 X 35 3/8 |
NO |
NO |
12+18+12 |
2237 |
2572 |
N/A |
N/A | |
|
45 X 36 |
44 3/8 X 35 3/8 |
NO |
21 + 24 |
NO |
2321 |
2670 |
N/A |
N/A | |
|
45 X 36 |
44 3/8 X 35 3/8 |
NO |
NO |
15+15+15 12+21+12 |
2406 |
2766 |
N/A |
N/A | |
|
48 X 36 |
47 3/8 X 35 3/8 |
NO |
24 + 24 |
NO |
2491 |
2864 |
N/A |
N/A | |
|
48 X 36 |
47 3/8 X 35 3/8 |
NO |
NO |
15+18+15 12+24+12 |
2575 |
2961 |
N/A |
N/A | |
|
51 X 36 |
50 3/8 X 35 3/8 |
NO |
NO |
15+21+15 |
2661 |
3061 |
N/A |
N/A | |
|
54 X 36 |
53 3/8 X 35 3/8 |
NO |
NO |
18+18+18 15+24+15 |
2745 |
3157 |
N/A |
N/A | |
|
57 X 36 |
56 3/8 X 35 3/8 |
NO |
NO |
18+21+18 |
2847 |
3275 |
N/A |
N/A | |
|
60 X 36 |
59 3/8 X 35 3/8 |
NO |
NO |
18+24+18 |
3016 |
3469 |
N/A |
N/A | |
|
63 X 36 |
62 3/8 X 35 3/8 |
NO |
NO |
21+21+21 |
3102 |
3566 |
N/A |
N/A | |
|
66 X 36 |
65 3/8 X 35 3/8 |
NO |
NO |
21+24+21 |
3187 |
3666 |
N/A |
N/A | |
|
69 X 36 |
68 3/8 X 35 3/8 |
NO |
NO |
24+21+24 |
3469 |
3991 |
N/A |
N/A | |
|
72 X 36 |
71 3/8 X 35 3/8 |
NO |
NO |
24+24+24 |
3660 |
4095 |
N/A |
N/A |
Looking for items in this collection as a wall mirror only? Click here.
Need a mounting kit to surface mount? Click here.
36″ HEIGHT DOUBLE STRIPS* OPTION: ALL PHAROS MULTIPLE DOOR CABINETS STANDARD WITH ONE STRIP OF LIGHT PER LEFT & RIGHT DOOR. WHEN REQUIRING TWO STRIPS OF LIGHT PER DOOR, ADD $405 TO THE COST OF THE CABINET AND SPECIFY DOUBLE STRIPS OPTION WHEN ORDERING.* TO ORDER THIS OPTION ADD A -2 FOLLOWING THE # OF DOORS IN YOUR CABINET’S MODEL NO. EXAMPLE: PHA 4536 3D-2 P 6 A (1). (THIS CABINET WOULD HAVE 2 STRIPS OF LIGHT IN EACH OUTER DOOR).
PHAROS COLLECTION (40” HEIGHT) 5 3/16 & 6 5/8” DEPTH
Available Narrow Door Finish Options:
AVAILABLE IN 3500 KELVIN OR 6000 KELVIN COLOR TEMPERATURE OPTION
Download our wiring manual here
|
MODEL NUMBER |
OUTER |
ROUGH |
SINGLE |
DOUBLE |
TRIPLE |
5 3/16 DEPTH
(1) |
6 5/8 DEPTH (2) |
5 3/16 DEPTH
(1) |
6 5/8 DEPTH (2) |
|---|---|---|---|---|---|---|---|---|---|
|
|
|
|
|
|
|
POL. |
POL. |
POL. |
POL. |
|
15 X 40 |
14 3/8 X 39 3/8 |
YES |
NO |
NO |
1193 |
1373 |
2362 |
2659 | |
|
18 X 40 |
17 3/8 X 39 3/8 |
YES |
NO |
NO |
1292 |
1485 |
2430 |
2727 | |
|
21 X 40 |
20 3/8 X 39 3/8 |
YES |
NO |
NO |
1359 |
1562 |
2508 |
2805 | |
|
24 X 40 |
23 3/8 X 39 3/8 |
YES |
NO |
NO |
1405 |
1616 |
2645 |
2942 | |
|
24 X 40 |
23 3/8 X 39 3/8 |
NO |
12 + 12 |
NO |
1504 |
1731 |
N/A |
N/A | |
|
27 X 40 |
26 3/8 X 39 3/8 |
NO |
12 + 15 |
NO |
1603 |
1844 |
N/A |
N/A | |
|
30 X 40 |
29 3/8 X 39 3/8 |
NO |
15 + 15 |
NO |
1701 |
1956 |
N/A |
N/A | |
|
30 X 40 |
29 3/8 X 39 3/8 |
NO |
12 + 18 |
NO |
1701 |
1956 |
N/A |
N/A | |
|
33 X 40 |
32 3/8 X 39 3/8 |
NO |
15 + 18 |
NO |
1798 |
2068 |
N/A |
N/A | |
|
36 X 40 |
35 3/8 X 39 3/8 |
NO |
18 + 18 |
NO |
1898 |
2185 |
N/A |
N/A | |
|
36 X 40 |
35 3/8 X 39 3/8 |
NO |
15 + 21 |
NO |
1898 |
2185 |
N/A |
N/A | |
|
36 X 40 |
35 3/8 X 39 3/8 |
NO |
NO |
12+12+12 |
2117 |
2435 |
N/A |
N/A | |
|
39 X 40 |
38 3/8 X 39 3/8 |
NO |
15 + 24 |
NO |
2249 |
2587 |
N/A |
N/A | |
|
42 X 40 |
41 3/8 X 39 3/8 |
NO |
21 + 21 |
NO |
2316 |
2662 |
N/A |
N/A | |
|
42 X 40 |
41 3/8 X 39 3/8 |
NO |
18 + 24 |
NO |
2316 |
2662 |
N/A |
N/A | |
|
42 X 40 |
41 3/8 X 39 3/8 |
NO |
NO |
12+18+12 |
2594 |
2983 |
N/A |
N/A | |
|
45 X 40 |
44 3/8 X 39 3/8 |
NO |
21 + 24 |
NO |
2692 |
3096 |
N/A |
N/A | |
|
45 X 40 |
44 3/8 X 39 3/8 |
NO |
NO |
15+15+15 12+21+12 |
2791 |
3209 |
N/A |
N/A | |
|
48 X 40 |
47 3/8 X 39 3/8 |
NO |
24 + 24 |
NO |
2889 |
3322 |
N/A |
N/A | |
|
48 X 40 |
47 3/8 X 39 3/8 |
NO |
NO |
15+18+15 12+24+12 |
2987 |
3437 |
N/A |
N/A | |
|
51 X 40 |
50 3/8 X 39 3/8 |
NO |
NO |
15+21+15 |
3087 |
3550 |
N/A |
N/A | |
|
54 X 40 |
53 3/8 X 39 3/8 |
NO |
NO |
18+18+18 15+24+15 |
3185 |
3662 |
N/A |
N/A | |
|
57 X 40 |
56 3/8 X 39 3/8 |
NO |
NO |
18+21+18 |
3304 |
3799 |
N/A |
N/A | |
|
60 X 40 |
59 3/8 X 39 3/8 |
NO |
NO |
18+24+18 |
3499 |
4024 |
N/A |
N/A | |
|
63 X 40 |
62 3/8 X 39 3/8 |
NO |
NO |
21+21+21 |
3598 |
4136 |
N/A |
N/A | |
|
66 X 40 |
65 3/8 X 39 3/8 |
NO |
NO |
21+24+21 |
3698 |
4253 |
N/A |
N/A | |
|
69 X 40 |
68 3/8 X 39 3/8 |
NO |
NO |
24+21+24 |
4025 |
4631 |
N/A |
N/A | |
|
72 X 40 |
71 3/8 X 39 3/8 |
NO |
NO |
24+24+24 |
4132 |
4755 |
N/A |
N/A |
Looking for items in this collection as a wall mirror only? Click here.
Need a mounting kit to surface mount? Click here.
40″ HEIGHT DOUBLE STRIPS* OPTION: ALL PHAROS MULTIPLE DOOR CABINETS STANDARD WITH ONE STRIP OF LIGHT PER LEFT & RIGHT DOOR. WHEN REQUIRING TWO STRIPS OF LIGHT PER DOOR, ADD $432 TO THE COST OF THE CABINET AND SPECIFY DOUBLE STRIPS OPTION WHEN ORDERING.* TO ORDER THIS OPTION ADD A -2 FOLLOWING THE # OF DOORS IN YOUR CABINET’S MODEL NO. EXAMPLE: PHA 4540 3D-2 P 6 A (1). (THIS CABINET WOULD HAVE 2 STRIPS OF LIGHT IN EACH OUTER DOOR).
Decorative Frames are available for this collection
Click here to view Frame Book.
MEDICINE CABINET HOUSING FINISH OPTIONS
MATTE SILVER
CHAMPAGNE*
